Description

BRAND NEW GENUINE BORGWARNER TURBOCHARGER

This is a BRAND NEW GENUINE BORGWARNER TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.

Fits the following:

Part Number: 310135
Interchangeable Number: 172495, 184119, 40910-0006, 40910-5006, 40910-5006S
OEM Number: 0R-5807, 0R5807, 7N-7748, 7N7748
Serial Number: 13Z9677-18011, 13Z13093-18023, 08Z37794-99999
Turbo Model: 3LM
Manufacturer: BorgWarner – 3K – Schwitzer

Engine: 3306, 3306B
Fuel: Diesel
Prefix: 01Y, 03X, 04X, 05X, 06X, 13W, 14X, 18B, 19B, 19X, 1FJ, 1KD, 20X, 23U, 24U, 25U, 26X, 2KD, 2MJ, 2TG, 30X, 31X, 32X, 33B, 33X, 36C, 37C, 3ED, 4LG, 4RC, 57U, 58Z, 5MD, 5YB, 61M, 61S, 64Z, 6FC, 6HC, 72V, 74W, 75W, 76J, 7JB, 7PC, 7XF, 8FC, 8KB, 8YC, 90P, 91P, 96U, 99Z, 9FK, 9KC, BWJ, C6G, MGC, P6G

Back Plate: 197652 (310010, 311708, 4N6863, 6N1527, 104244-0000, 408045-0034, 408206-0002, 408045-0051)(1100040360)
Bearing Housing: 158049 (181388)(0R5402, 6N1529)
CHRA: 310129 (7N7750)(Use 184120)(0R5534)
Compressor Cover: 184122 (7N7746)
Compressor Wheel: 184121 (7N7749)(Ind. 58.32 mm, Exd. 75 mm, 6+6 Blades)
Gasket (Oil Inlet): 210023 (311496)
Gasket (Oil Outlet): 210021 (147837, 210023, 215234, 52231586500)
Gasket (Turbine Inlet) Single Entry: 407294-0001 (312617)
Heat Shield: 188276 (6N1531)(409299-0001)
Repair Kit: 318385 (183223, 188210-0000)(318368)(6N7242)(1251133750)
Turbine Housing: 157926 (0R5411, 6N1521)
Turbine Housing: 157927 (7N7747)
Turbine Wheel: 158396 (193341)(Ind. 80.5 mm, Exd. 68.5 mm, 12 Blades)(6N1532)

Application:
Caterpillar 12G, 14G, 130G, 140G Motor Grader with 3306 Engine
Caterpillar 140, 141, 143, 153, 163, 4, 5, 55, 56, 56H 6, 6A, 6S, 6SU, D5B, D6D SR, D6D, D6E, D6F SR, D6G, D6H Track-Type Tractor with 3306 Engine
Caterpillar 951, 955, 977 Track-Type Loader with 3306 Engine
Caterpillar 966C, 966R Wheel-Type Loader with 3306 Engine
Caterpillar Earth Moving with 3306 Engine
Caterpillar Industrial with 3306, 3306B Engine

*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
